|Dimensions||20.2 × 12 × 13.5 cm|
Nominal ratio: 40:1
Actual Pressure ratio: 45:1
Displacement per stroke: 0.20 cu in / 3.35 cc
Max outlet pressure: 4,460 psi / 360 BARG
Connection size inlet/oulet: 0.375" NPT / 0.375" NPT
Availability: Stocked item
|Model No.||Actual Ratio||Displacement per Stroke||Max Outlet Pressure||Connection Size Inlet/Outlet||Price||Availability|
|PM22||25:1||0.37 cu in / 6.03 cc||2,900 psi / 224 BARG||0.375" NPT / 0.375" NPT||$621.00 ex tax||Stocked item|| ||3662100|
|PM40||45:1||0.20 cu in / 3.35 cc||4,460 psi / 360 BARG||0.375" NPT / 0.375" NPT||$633.00 ex tax||Stocked item|| ||3663300|
|PM60||64:1||0.14 cu in / 2.36 cc||7,424 psi / 512 BARG||0.375" NPT / 0.25" NPT||$639.00 ex tax||Stocked item|| ||3663900|
|PM100||100:1||0.09 cu in / 1.51 cc||12,035 psi / 830 BARG||0.25" NPT / 0.25" NPT||$644.00 ex tax||Stocked item|| ||3664400|
|PM6||7:1||1.29 cu in / 21.21 cc||842 psi / 58 BARG||0.375" NPT / 0.375" NPT||$644.00 ex tax||Stocked item|| ||3664400|
|PM9||10:1||0.92 cu in / 15.08 cc||1,160 psi / 80 BARG||0.375" NPT / 0.375" NPT||$656.00 ex tax||Stocked item|| ||3665600|
|PM15||16:1||0.58 cu in / 9.43 cc||1,856 psi / 128 BARG||0.375" NPT / 0.375" NPT||$656.00 ex tax||Assembled to order|| ||3665600|
|PM125||130:1||0.07 cu in / 1.15 cc||15,645 psi / 1,079 BARG||0.25" NPT / 0.25" NPT||$667.00 ex tax||Stocked item|| ||3666700|
